Emerson Unidrive M400 - Getting started; Network design considerations; Addressing

Unidrive M400 Quick Start Guide 15
Issue Number: 5
Figure 4-1 Pr 00.005 = AV (50 and 60 Hz)
Figure 4-2 Pr 00.005 = AI (50 and 60 Hz)
1
2
3
4
0V
Voltage speed reference
input (AI 1+)
AI 1-
Voltage speed
reference input (AI 2)
5
6
7
8
0V
Analog output 1
(motor frequency)
+ 10 V output
Analog output 2
(motor active current)
9
10
11
Digital output
(zero frequency)
Unassigned
12
13
14
15
16
17
Run reverse
Run forward
Analog input 1/
input 2 select
+ 24 V output
Jog Forward
Unassigned
+ 24 V output
10k
10k
1
2
3
4
0V
Current speed reference
input (AI 1+)
AI 1-
Voltage speed
reference input (AI 2)
5
6
7
8
0V
Analog output 1
(motor frequency)
+ 10 V output
Analog output 2
(motor active current)
9
10
11
Digital output
(zero frequency)
Unassigned
12
13
14
15
16
17
Run reverse
Run forward
Analog input 1/
input 2 select
+ 24 V output
Jog Forward
Unassigned
+ 24 V output
10k
Current speed
reference input
