24 Unidrive M400 Quick Start Guide
Issue Number: 5
6 Basic parameters (Menu 0)
Menu 0 is used to bring together various commonly used parameters for basic easy set up of the
drive. All the parameters in Menu 0 appear in other menus in the drive. Menus 22 can be used to
configure the parameters in Menu 0.
6.1 Menu 0: Basic parameters
Parameter
Range(Ú) Default(Ö)
Type
OL RFC-A OL RFC-A
00.001
Minimum Reference
Clamp
±VM_NEGATIVE_REF_
CLAMP1 Hz
0.00 Hz RW Num US
00.002
Maximum Reference
Clamp
±VM_POSITIVE_REF_
CLAMP Hz
50 Hz default: 50.00 Hz
60 Hz default: 60.00 Hz
RW Num US
00.003 Acceleration Rate 1 ±VM_ACCEL_RATE s 5.0 s RW Num US
00.004 Deceleration Rate 1 ±VM_ACCEL_RATE s 10.0 s RW Num US
00.005 Drive Configuration
AV (0), AI (1), AV Preset (2),
AI Preset (3), Preset (4),
Keypad (5), Keypad Ref (6),
Electronic Pot (7),
Torque Control (8),
Pid Control (9)
AV (0) RW Txt PT US
00.006 Motor Rated Current ±VM_RATED_CURRENT A
Maximum Heavy Duty
Rating
(11.032) A
RW Num RA US
00.007 Motor Rated Speed 0.0 to 80000.0 rpm
50 Hz
default:
1500.0
rpm
60 Hz
default:
1800.0
rpm
50 Hz
default:
1450.0 rpm
60 Hz
default:
1750.0 rpm
RW Num US
00.008 Motor Rated Voltage ±VM_AC_VOLTAGE_SET V
110 V drive: 230 V
200 V drive: 230 V
400 V drive 50 Hz: 400 V
400 V drive 60 Hz: 460 V
575 V drive: 575 V
690 V drive: 690 V
RW Num RA US
00.009
Motor Rated Power
Factor
0.00 to 1.00 0.85 RW Num RA US
00.010 User Security Status
Menu 0 (0), All Menus (1),
Read only Menu 0 (2),
Read only (3),
Status Only (4), No Access (5)
Menu 0 (0) RW Txt ND NC PT
00.012 Input Logic Polarity
Negative Logic (0) or
Positive Logic (1)
Positive Logic (1) RW Txt US
00.015 Jog Reference 0.00 to 300.00 Hz 1.50 Hz RW Num US
Unidrive M400 Quick Start Guide English Iss3.book Page 24 Wednesday, July 16, 2014 8:12 AM
