00.016 Analog Input 1 Mode
4-20 mA Stop (-6),
20-4 mA Stop (-5),
4-20 mA Low (-4),
20-4 mA Low (-3),
4-20 mA Hold (-2),
20-4 mA Hold (-1),
0-20 mA (0), 20-0 mA (1),
4-20 mA Trp (2),
20-4 mA Trp (3), 4-20 mA (4),
20-4 mA (5), Voltage (6)
Voltage (6) RW Txt US
00.017 Bipolar Reference Enable Off (0) or On (1) Off (0) RW Bit US
00.018 Preset Reference 1 ±VM_SPEED_FREQ_REF Hz 0.00 Hz RW Num US
00.025 User Security Code 0 to 9999 0 RW Num ND NC PT US
00.027
Power-up Keypad Control
Mode Reference
Reset (0), Last (1), Preset (2) Reset (0) RW Txt US
00.028 Ramp Mode Select
Fast (0), Standard (1),
Std boost (2),
Fast boost (3)
Standard (1) RW Txt US
00.029 Ramp Enable
Off (0) or On
(1)
On (1) RW Bit US
00.030 Parameter Cloning
None (0), Read (1), Program
(2),
Auto (3), Boot (4)
None (0) RW Txt NC US
00.031 Stop Mode
Coast (0), Ramp (1),
Ramp dc I (2), dc I (3),
Timed dc I (4), Disable (5),
No Ramp (6)
Ramp (1) RW Txt US
00.032
Dynamic V to F Select /
Flux Optimization Select
0 to 1 0 RW Num US
00.033 Catch A Spinning Motor
Disable (0), Enable (1),
Fwd Only (2), Rev Only (3)
Disable (0) RW Txt US
00.034 Digital Input 5 Select
Input (0), Therm Short Cct (1),
Thermistor (2), Therm No Trip
(3)
Input (0) RW Txt US
00.035 Digital Output 1 Control 0 to 21 0 RW US
00.036 Analog Output 1 Control 0 to 15 0 RW US
00.037
Maximum Switching
Frequency
0.667 (0),
1 (1), 2 (2),
3 (3), 4 (4),
6 (5), 8 (6),
12 (7),
16 (8) kHz
2 (2), 3 (3), 4
(4), 6 (5), 8 (6),
12 (7), 16 (8)
3 (3) kHz RW Txt US
00.038 Auto-tune 0 to 2 0 to 3 0 RW Num NC US
00.039 Motor Rated Frequency
0.00 to
VM_SPEED_FREQ_REF_
UNIPOLAR Hz
50Hz: 50.00 Hz
60Hz: 60.00 Hz
RW Num RA US
00.040 Number of Motor Poles* Automatic (0) to 32 (16) Poles Automatic (0) Poles RW Txt US
00.041 Control Mode
Ur S (0), Ur
(1), Fixed
(2),
Ur Auto (3),
Ur I (4),
Square (5)
Ur I (4) RW Txt US
00.042
Low Frequency Voltage
Boost
0.0 to 25.0 % 3.0 % RW Num US
Parameter
Range(Ú) Default(Ö)
Type
OL RFC-A OL RFC-A
Unidrive M400 Quick Start Guide English Iss3.book Page 25 Wednesday, July 16, 2014 8:12 AM
