20 • XEV22D I&O Manual 026-1206 Rev 3 13-DEC-2012
17 Specifications
Housing Self extinguishing ABS
Dimensions Case:
Front: 4 DIN modules, 70 mm x 135 mm with male and female connectors
Depth: 60 mm
Mounting:
DIN RAIL mounted in a omega (3) din rail
Protection IP20
Connections
Detachable screw terminal block ≤ 2.5 mm
2
wiring
Power Supply 24VAC/DC ±10%
Power Absorption
(depending on the valve)
20VA max
Display Three (3) digits with icons, red LEDs, height 14.2 mm
Inputs 1 temperature probe Pt1000 or NTC
1 pressure transducer 4 to 20mA or 0 to 5V
Digital Inputs 1 free of voltage
1 at high voltage
Outputs for Valve Bipolar or unipolar valves
Data Storage On the non-volatile memory (EEPROM)
Kind of Action 1B
Pollution Grade Normal
Software Class A
Temperature Operating: 0 to 60°C
Storage: -25 to 60 °C
Relative
Humidity
20 to 85% (no condensing)
Resolution 0.1°C or 1°F
Precision at 25°C ±0.7°C ±1 digit
Table 17-1 - XEV22D Specifications
