Ordering Code Wiring Guidelines • 3
4 Wiring Guidelines
DEVICE TYPE RETAIL SOLUTIONS
ANALOG TEMP SENSOR
DIGITAL INPUT
BELDEN #8761 #22-2 SHIELDED
Retail Solutions P/N 035-0002
RS-485 NETWORK BELDEN #8761 #22-2 SHIELDED
Retail Solutions P/N 035-0002
BELDEN #8641 #24-2 SHIELDED
Retail Solutions P/N 135-8641
PRESSURE TRANSDUCER **BELDEN #8771 #22-3 SHIELDED
Retail Solutions P/N 135-8771
**#8771 for alternate 600v rated wire use BELDEN #8618 16
AWG
*STEPPER VALVE Use valve manufacturer’s harness with a maximum length not
to exceed 30 feet (10 meters).
POWER LOADS AND VALVE
Allow a maximum wire size of 14 AWG (2 mm
2
).
Table 4-1 - Wiring Guidelines
