Emerson XR75CX - 8.11. Digital Inputs Polarity

Digital Inputs Polarity Digital Inputs • 15
8.11.Digital Inputs Polarity
The digital input polarity depends on the i1P and
i2P parameters.
• i1P or i2P = CL: the input is activated by closing the
contact.
• i1P or i2P = oP: the input is activated by opening
the contact
