6 • XR75CX I&O Manual 026-1210 Rev 0 09-FEB-2011
6 Main Functions
6.1. To Set the Current
Time and Day (Only For
Devices With RTC)
1. When the device is switched ON, it’s neces-
sary to program the time and day.
2. Enter the Pr1 programming menu, by pushing
the SET + DOWN arrow keys for 3 seconds.
3. The rtc parameter is displayed. Push the SET
key to enter the real time clock menu.
4. The Hur (hour) parameter is displayed.
5. Push the SET key and set current hour by the
UP and DOWN arrow keys, then push SET to
confirm the value.
6. Repeat the same operations on the Min (min-
utes) and dAy (day) parameters.
To exit: Push the SET + UP arrow keys or wait 15
seconds (without pushing any keys.)
6.2. How to See the
Setpoint
1.Push and immediately release the
SET key: the display will show the
setpoint value.
2. Push and immediately release the SET key or
wait for 5 seconds to display the probe value
again.
6.3. How to Change the
Setpoint
1. Push and hold the SET key for more than 2
seconds to change the setpoint value.
2. The value of the setpoint will be displayed
and the °C or °F LED starts blinking.
3. To change the setpoint value push the UP or
DOWN arrows within 10 seconds.
4. To memorize the new setpoint value, push the
SET key again or wait 10 seconds.
6.4. How to Start a Manual
Defrost
Push and hold the DEF key for
more than 2 seconds and a manu-
al defrost will start.
6.5. How to Change a
Parameter Value
To change the parameter’s value follow these
steps:
1. Enter the Programming mode by pressing the
SET + DOWN arrow keys for 3 seconds (the
°C or °F LED starts blinking).
2. Select the required parameter. Press the SET
key to display its value.
3. Use the the UP or DOWN arrows to change
its value.
4. Press SET to store the new value and move to
the next parameter.
5. To exit: Press SET + UP arrow or wait 15 sec-
onds without pressing a key.
6.6. The Hidden Menu
The hidden menu includes all the parameters of
the controller.
6.6.1. How to Enter the Hidden
Menu
1. Enter the Programming mode by pressing the
SET + DOWN arrow keys for three (3) sec-
NOTE: The set value is stored even when the
time-out expires and ends the procedure.
