EMI S1CA9000 - CASSETTE Dimensions

www.enviromaster.com
Cassette Air Handler
44
F
E
D
Control
Box
3.73
4.88
3.50
2.50
4.69
7.19
19.50
22.47
23.27
1.50
TYP
C
Small Cabinet • Cassette 12 • 9,000-12,000 Btuh
CASSETTE DIMENSIONS
FEATURE QTY. SIZE
A
Optional
Discharge
Knockout
3 5¼” Ø
B
Fresh Air Inlet
Knockout
2 1¼” x 2½”
C
Condensate
Discharge
1
½” Ø
D Suction 1
½” Ø
E Liquid 1
¼” Ø
F
Condensate
Pump Access
1
-
Note: All dimensions in inches.
Cassette 12
25.00
25.00
8.13
2.88
1.41
2.04
22.57
2.67
REF
2.16
REF
11.34
REF
1.73
22.50
5.13
25.86
12.76
.875Ø
