UserReading Adjustment
UpLimit AnalogueValue
Parameter
Pressincrementbuttonforaccessingtothe
userreadingadjustmentuplimitanalogue
valueenteringscreen.PressENTER
buttonforaccessingtothenextparameter
PressENTERbuttonfor
accessingtothenext
parameter
UserReading Adjustment
UpLimit AnalogueValue
EnteringScreen
P
AS
ASET
i
If no operation is performed in Programming mode for 20 seconds, device turns to
main operation screen automatically.
PressENTERbuttonfor
accessingtoprogramming
screen
30
UserReading Adjustment
LowLimit Analogue
ValueParameter
At this state, the equivalent voltage or current for up
reading adjustment value parameter is applied
to process input of the devices. When increment button
is pressed, display starts to blink. It means, the analogue
value at process input is saved as a user reading
adjustment up limit analogue value
P
AS
ASET
PressENTERbuttonfor
accessingtothenext
parameter
UserReading Adjustment
UpLimit AnalogueValue
Parameter
ProgrammingScreenProgrammingScreen
i
Other programming mode parameters can be accessed,
observed and changed
