7.FailureMessagesinESM3700DigitalProcessIndicator
ProcessIndicator
ESM-3700
P
AS
ASET
If the equivalent voltage or current applied
to the process input while in or
parameter for user reading
adjustment is out of the standard scale, this
error message are shown on the display
Example-1:
For process Input type selected as ,
If the applied voltage while in
parameter or parameter is lower
than 0 V or
0-10 V
upper than 10 V , when the
decrement or increment button is pressed for
saving the analog value this errror message
is shown on the display and applied voltage
value is not saved.
Press any button to clear error
message from the display and turn to the user
reading adjustment analaog value entering
screen
Z
Z Z
ProcessIndicator
ESM-3700
P
AS
ASET
If the difference between the equivalent
voltage or current applied to the process input
while in and parameters
is lower than the
%50 of the standard scale,
5 V ,
for user reading adjustment
this error
message are shown on the display
Example-2:
For process Input type selected as 0-10 V ,
If the difference between the applied voltages
in and parameters is lower
than the when the decrement or
increment button is pressed for saving the
analog value this errror message is shown on
the display and applied voltage value is not
saved.
Press any button to clear error
message from the display and turn to the user
reading adjustment analaog value entering
screen
