ESM-4420 ( 48x48 DIN 1/16 )
ESM-4920 ( 96x48 DIN 1/8 )
ESM-7720 ( 72x72 DIN S�ze )
ESM-9420 ( 48x96 DIN 1/8 )
ESM-9920 ( 96x96 DIN 1/4 )
1- Sensor fa�lure �n analog �nputs. Sensor
connect�on �s wrong or there �s no sensor
connect�on.
2- If value that �s read from the analog �nput �s
lower than process set low l�m�t parameter
, value on the top d�splay starts to bl�nk
l�ke on the p�cture.
3- If value that �s read from the analog �nput �s
h�gher than process set h�gh l�m�t parameter
value , value on the top d�splay starts to
bl�nk l�ke on the p�cture.
4- If programm�ng sect�on enter�ng password
�s d�fferent from “0” and user accesses to the
parameter by ASET/OK button w�thout
enter�ng the password and wants to change a
parameter, the warn�ng message �s shown on
the bottom d�splay as shown on the left.
Dev�ce does not allow to do any changes
w�thout enter�ng the password correctly.
5- In programm�ng sect�on, when Tune
operat�on �s selected , �f warn�ng wh�ch �s
shown on the left bl�nks �n operat�on screen
for 10 seconds, �t means that start cond�t�ons
�s not okay for Tune operat�on.
Before beg�nn�ng �nstallat�on of th�s product, please
read the �nstruct�on manual and warn�ngs below
In package ,
-One p�ece un�t
-Two p�eces mount�ng clamp
-One p�ece �nstruct�on manual
A v�sual �nspect�on of th�s product for poss�ble damage occured
dur�ng sh�pment �s recommended before �nstallat�on. It �s your
respons�b�l�ty to ensure that qual�f�ed mechan�cal and electr�cal
techn�c�ans �nstall th�s product.
If there �s danger of ser�ous acc�dent result�ng from a fa�lure or
defect �n th�s un�t, power off the system and the electr�cal
connect�on of the dev�ce from the system.
The un�t �s normally suppl�ed w�thout a power sw�tch or a fuse. Use
power sw�tch and fuse as requ�red.
Be sure to use the rated power supply voltage to protect the un�t
aga�nst damage and to prevent fa�lure.
Keep the power off unt�l all of the w�r�ng �s completed so that
electr�c shock and trouble w�th the un�t can be prevented.
Never attempt to d�sassemble, mod�fy or repa�r th�s un�t.
Tamper�ng w�th the un�t may results �n malfunct�on, electr�c shock
or f�re.
Do not use the un�t �n combust�ble or explos�ve gaseous
atmospheres. Dur�ng the equ�pment �s putted �n hole on the metal
panel wh�le mechan�cal �nstallat�on some metal burrs can cause
�njury on hands, you must be careful.
Montage of the product on a system must be done w�th �t’s
mount�ng clamp. Do not do the montage of the dev�ce w�th
�nappropr�ate mount�ng clamp. Be sure that dev�ce w�ll not fall
wh�le do�ng the montage.
It �s your respons�b�l�ty �f th�s equ�pment �s used �n a manner not
spec�f�ed �n th�s �nstruct�on manual.
EMKO Elektron�k warrants that the equ�pment del�vered �s free
from defects �n mater�al and workmansh�p. Th�s warranty �s
prov�ded for a per�od of two years. The warranty per�od starts from
the del�very date.
Th�s warranty �s �n force �f duty and respons�b�l�t�es wh�ch are
determ�ned �n warranty document and �nstruct�on manual performs
Repa�rs should only be performed by tra�ned and spec�al�zed
personnel. Cut power to the dev�ce before access�ng �nternal parts.
Do not clean the case w�th hydrocarbon-based solvents (Petrol,
Tr�chlorethylene etc.). Use of these solvents can reduce the
mechan�cal rel�ab�l�ty of the dev�ce. Use a cloth dampened �n ethyl
alcohol or water to clean the external plast�c case.
Manufacturer Informat�on:
Emko Elektron�k Sanay� ve T�caret A.Ş.
Dem�rtaş Organ�ze Sanay� Bölges� Karanf�l Sk. No:6 16369
BURSA/TURKEY
Phone : +90 224 261 1900
Fax : +90 224 261 1912
Repa�r and Ma�ntenance Serv�ce Informat�on:
Emko Elektron�k Sanay� ve T�caret A.Ş.
Dem�rtaş Organ�ze Sanay� Bölges� Karanf�l Sk. No:6 16369
BURSA/TURKEY
Phone : +90 224 261 1900
Fax : +90 224 261 1912
Thank you very much for your preference to
use Emko Elektron�k products, please v�s�t our
web page to download deta�led user manual.
Error Messages
Installat�on
Warranty
Ma�ntenance
Other Informat�ons
