EMKO ESM Series User Manual

3
1.5 Maintenance
1.6 Manufacturer Company
Dimension :
ESM-4420 : (48 x 48mm, Depth : 95mm)
ESM-4920 : (96 x 48mm, Depth : 94.5mm)
ESM-7720 : (72 x 72mm, Depth : 95.5mm)
ESM-9420 : (48 x 96mm, Depth : 94.5mm)
ESM-9920 : (96 x 96mm, Depth : 96mm)
Panel CutOut :
ESM-4420 : (46 x 46mm)
ESM-4920 : (92 x 46mm)
ESM-7720 : (69 x 69mm)
ESM-9420 : (46 x 92mm)
ESM-9920 : (92 x 92mm)
8
TC
Process Input
1
9
2
11
3
12 13
14
Pt-100
CAT II
ESM-4420
Y
c
Output-1
( Process Output or
Alarm Output-2 )
Output
( Alarm Output-1 )
-2
C NO
10
4
5 6
7
5A@250VV
5A@250VV
NCNO C
( - )
( + )
Note-1
Supply
Switch
230 VV
50/60 Hz
N
L
1A V T
Fuse
Output-3
( SSR Output )
_
+
Max. 24 mA, 12V
Process Input
CAT II
ESM-4920
Y
c
Output
Alarm Output-2 )
-1
( Process Output or
Output
( Alarm )
-2
Output-1
5A@250VV
NCNO C
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
5A@250VV
NCNO C
TC
Pt-100
( - )
( + )
Note-1
Supply
Switch
230 VV
50/60 Hz
N
L
1A V T
Fuse
Output
(SSR )
-3
Output
+
_
Max. 24 mA, 12V
Electrical Wirings
ENGLISH

EMKO ESM Series Specifications

General

Control Type	PID, On/Off
Input Type	Thermocouple, RTD
Output Type	Relay, SSR, Analog
Display	LED
Power Supply	100-240V AC
Resolution	0.1°C
Communication	RS485
Dimensions	48x48mm, 96x96mm
