EMMO The X - Rear Wheel Assembly Instructions

13
Rear Wheel Assembly Instructions
1. First, remove the two screws that hold the plastic plates on both sides of rear wheel. See
figure 1-5:
figure 1-5
2. Remove the screw from the end of Brake Cable, and then pull the cable out. See figure 1-6:
figure 1-6
3. Remove the tightening screw. See figure 1-7 & figure 1-8
figure 1-7
figure 1-8
