Front Wheel Removal Instructions
1. Remove the two nuts from both sides of the front wheel. See figure 1-10
figure 1-10
2. Remove the screw from the end of Brake Cable, and then pull the cable out. Then remove the
axle and spacer as shown below in figure 1-12 & 1-13.
figure 1-11 figure1-12 figure1-13
3. Remove the front wheel.
Front Wheel Installation Instructions
1. Set your bike on a strong table or workbench to make access easier.
2. Lift the front forks and install the front wheel. Ensure the locking washers are inserted into
the holes on the forks.
3. Insert the axle and spacer as shown above (in reverse)
4. Install the two nuts on the end of the axle and tighten.
