140 Functional Description Emotron AB 01-3694-01r2
The first row indicates the analogue inputs.
1AnIn 1
2AnIn 2
Reading downwards from the first row to the second row the
status of the belonging input is shown in %:
-100% AnIn1 has a negative 100% input value
65% AnIn2 has a 65% input value
So the example in Fig. 113 indicates that both the Analogue
inputs are active.
Analogue Input Status [726]
Indicates the status of the analogue inputs 3 and 4.
Fig. 114 Analogue input status
Communication information
Analogue Output Status [727]
Indicates the status of the analogue outputs. Fig. 115. E.g. if
4-20 mA output is used, the value 20% equals to 4 mA.
Fig. 115 Analogue output status
Communication information
The first row indicates the Analogue outputs.
1 AnOut 1
2 AnOut 2
Reading downwards from the first row to the second row the
status of the belonging input is shown in %:
-100% AnOut1 has a negative 100% input value
65% AnOut1 has a 65% input value
The example in Fig. 115 indicates that both the Analogue
outputs are active.
I/O board Status [728] - [72A]
Indicates the status for the additional I/O on option boards
1 (B1), 2 (B2) and 3 (B3).
Communication information
11.8.3 Stored values [730]
The shown values are the actual values built up over time.
Values are stored at power down and updated again at power
up.
Run Time [731]
Displays the total time that the VSD has been in the Run
Mode.
Communication information
Modbus Instance no/DeviceNet no: 31021, 31022
Profibus slot/index 121/165, 121/166
Fieldbus format Long, 1=1%
Modbus format EInt
Modbus Instance no/DeviceNet no: 31023, 31024
Profibus slot/index 121/167, 121/168
Fieldbus format Long, 1=1%
Modbus format EInt
726 AnIn 3 4
Stp -100% 65%
727 AnOut 1 2
Stp -100% 65%
Modbus Instance no/DeviceNet no: 31025 - 31027
Profibus slot/index 121/170 - 172
Fieldbus format UInt, bit 0=DigIn1
bit 1=DigIn2
bit 2=DigIn3
bit 8=Relay1
bit 9=Relay2
bit 10=Relay3
Modbus format
Unit: h: m: s (hours: minutes: seconds)
Range: 0h: 0m: 0s–65535h: 59m: 59s
Modbus Instance no/DeviceNet no:
31028 hours
31029 minutes
31030 seconds
Profibus slot/index
121/172
121/173
121/174
Fieldbus format UInt, 1=1h/m/s
Modbus format UInt, 1=1h/m/s
728 IO B1
Stp RE000 DI10
731 Run Time
Stp h:m:s
