Emotron FDU40-003 - Control Signals

Emotron AB 01-3694-01r2 Technical Data 163
14.8 Control signals
Ta b le 4 4
Terminal Name: Function (Default): Signal: Type:
1 +10 V +10 VDC Supply voltage +10 VDC, max 10 mA output
2 AnIn1 Process reference
0 -10 VDC or 0/4–20 mA
bipolar: -10 - +10 VDC or -20 - +20 mA
analogue input
3 AnIn2 Off
0 -10 VDC or 0/4–20 mA
bipolar: -10 - +10 VDC or -20 - +20 mA
analogue input
4 AnIn3 Off
0 -10 VDC or 0/4–20 mA
bipolar: -10 - +10 VDC or -20 - +20 mA
analogue input
5 AnIn4 Off
0 -10 VDC or 0/4–20 mA
bipolar: -10 - +10 VDC or -20 - +20 mA
analogue input
6 -10 V -10VDC Supply voltage -10 VDC, max 10 mA output
7 Common Signal ground 0V output
8 DigIn 1 RunL 0-8/24 VDC digital input
9 DigIn 2 RunR 0-8/24 VDC digital input
10 DigIn 3 Off 0-8/24 VDC digital input
11 +24 V +24VDC Supply voltage +24 VDC, 100 mA output
12 Common Signal ground 0 V output
13 AnOut 1 Min speed to max speed 0 ±10 VDC or 0/4– +20 mA analogue output
14 AnOut 2 0 to max torque 0 ±10 VDC or 0/4– +20 mA analogue output
15 Common Signal ground 0 V output
16 DigIn 4 Off 0-8/24 VDC digital input
17 DigIn 5 Off 0-8/24 VDC digital input
18 DigIn 6 Off 0-8/24 VDC digital input
19 DigIn 7 Off 0-8/24 VDC digital input
20 DigOut 1 Ready 24 VDC, 100 mA digital output
21 DigOut 2 Brake 24 VDC, 100 mA digital output
22 DigIn 8 RESET 0-8/24 VDC digital input
Terminal X2
31 N/C 1 Relay 1 output
Trip, active when the
VSD is in a TRIP condition
N/C is opened when the relay is active
(valid for all relays)
N/O is closed when the relay is active
(valid for all relays)
potential free change over
0.1 – 2 A/U
max
250 VAC or 42 VDC
relay output
32 COM 1
33 N/O 1
41 N/C 2
Relay 2 Output
Run, active when the
VSD is started
potential free change over
0.1 – 2 A/U
max
250 VAC or 42 VDC
relay output
42 COM 2
43 N/O 2
Terminal X3
51 COM 3
Relay 3 Output
Off
potential free change over
0.1 – 2 A/U
max
250 VAC or 42 VDC
relay output
52 N/O 3
