EA2350 EA4150
Rated Power Output (RMS)
At 4 Ohms load / 13.8V (THD<=0.1%)
All channels driven simultaneously 350Wx2 151Wx4
Rated Power Output (RMS)
At 4 Ohms load / 13.8V (THD<=1%)
All channels driven simultaneously 370Wx2 160Wx4
Rated Power Output (RMS)
At 2 Ohms load / 13.8V (THD<=0.1%)
All channels driven simultaneously 680Wx2 260Wx4
Rated Power Output (RMS)
At 2 Ohms load / 13.8V (THD<=1%)
All channels driven simultaneously 710Wx2 273Wx4
Rated Power Output (RMS)
At 4 Ohms load / 13.8V (THD<=0.1%)
All channels driven simultaneously 1200Wx1 Bridged 505Wx2 Bridged
Damping Factor
All Channels stereo @ 4Ohms/100Hz > 200
Signal-to-Noise Ratio
(All channels) > 93 dB
Frequency Response
(all channels, frequency filtering
controls deactivated) 10Hz - 50 kHz (+0 dB / - 1 dB)
Channel Separation > 60 dB
(all channels)
Input Sensitivity
(all channels) 200 mV - 9.4V
Integrated Active Filtering
Slope Rates 12 dB /octave
Cross-Over Frequency
High Pass continuously variable 10 - 400 Hz
Low Pass continuously variable 40 - 400Hz
Fuses 2 x 80 A 2x50A
Dimensions (W x H x D) 580 x 71 x 277 mm 530 x 71 x 277mm
30
8. TECHNICAL SPECIFICATIONS
