30794-5-0314Page 30
IP ELECTRONIC SYSTEM WIRING DIAGRAM
If any of the original wire as supplied with this unit must be replaced, it must be replaced with equivalent gauge and temperature
rated wire.
This appliance is only for use with the type of gas indicated on the rating plate and may be installed in an aftermarket, permanently
located, manufactured (mobile) home where not prohibited by local codes. This appliance is not convertible for use with other gases,
unless a certied kit is used.
CAUTION
Do not operate the appliance with panel(s) removed, cracked or broken. Replacement of the panel(s) should be done by a
licensed or qualied service person.
WARNING
Improper installation, adjustment, alteration, service or maintenance can cause property damage, personal injury or loss of life. Instal-
lation and service must be performed by a qualied installer, service agency or the gas supplier.
