CIB4-1 OPTIONAL BLOWER INSTALLATION INSTRUCTIONS - DVP20CC
PARTS LIST
INDEX NUMBER PART NUMBER DESCRIPTION
1 R1454 Brass Bushing (4 Required)
2 R1499 Rubber Grommet (4 Required)
3 CI002 Blower Housing
4 R1517 Tinnerman Clip (4 Required)
5 R2804A Blower Assembly
6 CI003 Blower Housing Cover
7 R2099 Cord Set
8 R3767A Wire Harness
9 24222 Fan Control Bracket
10 R2503 Fan Control
11 R2805 Auto/Off/On Switch
12 R1410 Bushing 7/8” Diameter
