30794-5-0314Page 42
CASTING PARTS LIST
USE ONLY MANUFACTURER'S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR DEATH.
PLEASE NOTE: When ordering parts, it is very important that part number and description of part coincide.
INDEX
NO.
PART NO.
DESCRIPTION
DVP20CC DVP30CC
COMMON PARTS
11 R9671 R9671
INSERT TAB
(4 REQUIRED)
NS N/A R9669
HINGE PIN
(4 REQUIRED)
NS R9670 R9670
BOLT, 1/4-20 X 1/2”
(24 REQUIRED)
MATTE BLACK
1 N/A R11354
VENT OPENING INSERT
MIDDLE
2 N/A R9538 TOP INSERT - RIGHT
3 N/A R9537 TOP INSERT - LEFT
4 R11307 R9536 CASTING TOP
5 R11309 R9666 CASTING FRONT
6 R11306 R9535 CASTING SIDE - RIGHT
7 R11305 R9534 CASTING SIDE - LEFT
8 N/A R9668 CASTING DOOR - RIGHT
9 N/A R9667 CASTING DOOR - LEFT
10 24191 24191
FIREBOX SUPPORT
BRACKET (2 REQUIRED)
12 R11304 R9533 CASTING LEG B
13 R11303 R9532 CASTING LEG A
MATTE PEWTER
1 N/A R11356
VENT OPENING INSERT
MIDDLE
2 N/A R9554 TOP INSERT - RIGHT
3 N/A R9553 TOP INSERT - LEFT
4 N/A R9552 CASTING TOP
5 N/A R9693 CASTING FRONT
6 N/A R9551 CASTING SIDE - RIGHT
7 N/A R9550 CASTING SIDE - LEFT
8 N/A R9695 CASTING DOOR - RIGHT
9 N/A R9694 CASTING DOOR - LEFT
10 N/A 24191
FIREBOX SUPPORT
BRACKET (2 REQUIRED)
12 N/A R9549 CASTING LEG B
13 N/A R9548 CASTING LEG A
PORCELAIN BLACK
1 N/A R11355
VENT OPENING INSERT
MIDDLE
2 N/A R9570 TOP INSERT - RIGHT
3 N/A R9569 TOP INSERT - LEFT
4 R11314 R9568 CASTING TOP
5 R11316 R9681 CASTING FRONT
6 R11313 R9567 CASTING SIDE - RIGHT
7 R11312 R9566 CASTING SIDE - LEFT
8 N/A R9683 CASTING DOOR - RIGHT
9 N/A R9682 CASTING DOOR - LEFT
10 24191 24191
FIREBOX SUPPORT
BRACKET (2 REQUIRED)
12 R11311 R9565 CASTING LEG B
13 R11310 R9564 CASTING LEG A
PORCELAIN SAND
1 N/A R11358
VENT OPENING INSERT
MIDDLE
2 N/A R9586 TOP INSERT - RIGHT
3 N/A R9585 TOP INSERT - LEFT
4 N/A R9584 CASTING TOP
5 N/A R9700 CASTING FRONT
6 N/A R9583 CASTING SIDE - RIGHT
7 N/A R9582 CASTING SIDE - LEFT
8 N/A R9702 CASTING DOOR - RIGHT
9 N/A R9701 CASTING DOOR - LEFT
10 N/A 24191
FIREBOX SUPPORT
BRACKET (2 REQUIRED)
12 N/A R9581 CASTING LEG B
13 N/A R9580 CASTING LEG A
PORCELAIN MAHOGANY
1 N/A R11356
VENT OPENING INSERT
MIDDLE
2 N/A R9602 TOP INSERT - RIGHT
3 N/A R9601 TOP INSERT - LEFT
4 R11321 R9600 CASTING TOP
5 R11323 R9707 CASTING FRONT
6 R11320 R9599 CASTING SIDE - RIGHT
7 R11319 R9598 CASTING SIDE - LEFT
8 N/A R9709 CASTING DOOR - RIGHT
9 N/A R9708 CASTING DOOR - LEFT
10 24191 24191
FIREBOX SUPPORT
BRACKET (2 REQUIRED)
12 R11318 R9597 CASTING LEG B
13 R11317 R9596 CASTING LEG A
INDEX
NO.
PART NO.
DESCRIPTION
DVP20CC DVP30CC
