OM265EN issue 16
15
Controls and Markings
Megapulse Senior 265 control panel
Fig. 3 Megapulse Senior 265 control panel
Stand-by/On
LED
Control knob
IEC symbol
848-01-26
variability in
steps
LCD touch
screen
ON/OFF
Button
IEC symbol 5007
