TECHNICAL INFORMATION
FOR THE
5000 CONTROLLER
Dimensions: 330mm x 450mm x 116mm
Operating Frequencies: VHF – 173.2 MHz – 173.5Mhz (receiver)
UHF – 458.5 MHz – 589.5 MHz (transmitter)
Operating Temperature -10 to 55 degrees C
Humidity Up to 75% non-Condensing.
Channel Spacing: 25 kHz
Output Transmitter Power 0.75W (500 mW) ( + 27DBH)
Supply 240v 50 Hz
Operating Voltages 24v DC nominal
Battery space 2 x 12volt 7Ah batteries not supplied
Inputs 1 x 27v DC
Outputs 2 x 0.25amp 24v DC sounder outputs
2 x auxiliary fire relays
2 x auxiliary fault relays
1 x RS 485 serial port
1 x RS 232 serial port
Standards Designed to comply to BS5839 part 4 and
EN54 - 2
