EMX IRB-4X - Controls and Indicators; Indicator Lights; Adjustment Controls; Connections

IRB-4X™ Operating Instructions 4
Document no. 10060104
Controls and Indicators
Indicators Controls
Transmitter Receiver
Receiver
Connections
Transmitter
Receiver
Power
Power Positive(+)
Power Positive(+)
Power
Power Negative(-)
Power Negative(-)
Common
Internal Relay Common Output
Normally Closed
Internal Relay Normally Closed Output
Normally Open
Internal Relay Normally Open Output
Terminal Connection on receiver from left to right are N/C, Com, N/O, Power -, Power +
Sensitivity
Continuously adjustable single
turn potentiometer figure 2
(1)IRB-4X-T has a 0 – 15 second
relay timer to extend the relay
output time figure 2
Green LED
Power Indicator
Green LED
Power Indicator
Red LED
Detection Indication
