EMX MVP D-TEK - Specifications

MVP D-TEK™ Operating Instructions 3
Document no. 10000104
Specifications
Specifications
Power Supply
12 Volt DC – 220 Volt AC self adjusting
Power Supply Tolerance
+/- 20% of power rating
Current Draw
19.2 mA maximum
Housing Material
Extruded Anodized Aluminum
H=3.25”(83mm), W=2.56”(40mm) D=3.65” (90mm)
Relay Type
(2) DPST 1A@30VDC
Temperature Range
-40 to 180 Degrees Fahrenheit
Connector
11 Pin Octal compatible with DIN rail mount socket or wire
harness
Loop Inductance Range
20 to 2000 micro henries with “Q” factor of 5 or higher
Loop Input
Transformer Isolated
Power On Indicator
Green T-1 LED
Detect Indicator
Red T-1¾ LED
Surge Protection
MOV, Neon and Silicon Protection Devices
Tuning
Detector automatically tunes to the loop after the power
application or reset
Tracking
Detector automatically tracks and compensates for
environmental changes
Environmental Protection
Circuit board is conformal coated to resist moisture
Frequency Counter
Counts Loop frequency, each blink represents 10KHz.
Counts between 3 to 13 blinks confirms that the detector is
tuned to the loop.
Power Indicator
Solid lighted green LED indicates power
Loop Failure Indicator
Slow blinking green LED indicates loop failure
Loop Failure Memory
Fast consecutive green blinking LED indicates past loop
problems that healed
Detect Indicator
Solid lighted red LED indicates detection
Extend Indicator
Blinking red LED after vehicle leaves the loop indicates time
extend
4 minute limit
Blinking red LED during vehicle detection indicates that 4
minute limit has expired.
