P58 Cooling Time 0-600 sec 180 sec
P59 Fail to stop delay 4-120 sec 30 sec
P60 Engine stabilization time 2-60 sec 10 sec
P61 Engine protection delay after
stopping
1-60 sec 3 sec
P62 Current transformer primary 5-900 200
P63 Parameter menu current multiplier 0: x1 mode
1: x10 mode
0
P64 Over current level 1-990 A 159 A
P65 Over current alarm delay 2-250 sec 30 sec
P66 High coolant temperature level 80 C – 140 C (176 – 284 F) 105 C (221 F)
P67 Battery low alarm level 0-40 V 24.0
P68 Battery high alarm level 0-40 V 30.0
P69 Automatic parameter load 0-41 10
P70 Periodic service time 10-5000 50
P71 Engine hour adjustment 0.0 - 99999.0 hour 0
P72 Clear last ten alarm Yes/ No
P73 Clear periodic service alarm Yes/ No
P74 Return to technician factory defaults Yes/ No
Calibration Parameters
P75 Calibration menu password 0-999 070
P76 Mains Vr gain 0.01-9.99 0.87
P77 Mains Vs gain 0.01-9.99 0.87
P78 Mains Vt gain 0.01-9.99 0.87
P79 Generator Vr gain 0.01-9.99 0.87
P80 Generator Vs gain 0.01-9.99 0.87
P81 Generator Vt gain 0.01-9.99 0.87
P82 Generator Ir gain 0.01-9.99 3.53
P83 Generator Is gain 0.01-9.99 3.53
P84 Generator It gain 0.01-9.99 3.53
P85 Battery Voltage gain 0.01-9.99 0.54
P86 Mains Vr offset -29,+29 V 0
P87 Mains Vs offset -29,+29 V 0
P88 Mains Vt offset -29,+29 V 0
P89 Generator Vr offset -29,+29 V 0
P90 Generator Vs offset -29,+29 V 0
P91 Generator Vt offset -29,+29 V 0
P92 Battery voltage offset -9.9,+9.9 0.8
P93 Oil pressure offset -9.9,+9.9 0.0
P94 Temperature offset -9,+9 0
P95 Generator Ir offset -0.99, +0.99 (for 5 A ) 0.00
P96 Generator Is offset -0.99, +0.99 (for 5 A ) 0.00
P97 Generator It offset -0.99, +0.99 (for 5 A ) 0.00
P98 Return to calibration factory defaults Yes / No
P99 Mains contactor control in off mode 0: No
1: Yes
1
CHANGED PARAMETERS FOR GENSET MODELS
Initial parameter settings are for genset model 10. Parameter settings are different for other
genset models. Parameters that are different from model 10 parameters are as following table.
Model number is used to select genset model in parameter 69
Models
Number
Changed
Parameters
0 P15 → 1
P62 →100
P45 → 3
P64 → 29
P52 → 1
P67 → 9
P53 → 0
P68 → 15
1 P15 → 1
P62 →100
P45 → 3
P64 → 36
P52 → 1
P67 → 9
P53 → 0
P68 → 15
