Page 13
WI-FI (OPTIONAL)
This menu allows you to connect
your in.touch module to a Wi-Fi
network or to change its network.
This menu is only visible when the
in.touch module is installed.
To connect your in.touch module
to a wireless network, use the
or buttons to go to the Wi-Fi
option in the Settings menu and (middle left) lit button to
select it.
After a few seconds the available networks will appear on the screen, as
well as their signal strength.
Use the or buttons to
move through the list. Select your
network by pressing the middle left
button (top swim jets).
If the Wi-Fi network is password
protected enter it when prompted.
• Use the or buttons to
choose your letters.
• Use (lower right) lit button to move the curser forward.
• Use (top right) lit button to change the type of character.
(uppercase, lowercase, number, symbol).
• Use (lower left) lit button to backspace.
• Use (middle left) lit button to confirm.
If no password is required the in.touch
will connect automatically.
Once the in.touch module is connected
to a Wi-Fi network a green check mark
will appear in the Wi-Fi menu, and
the network name will appear in the
Settings menu.
AUDIO IN.STREAM 2 (OPTIONAL)
If your
fitness system
has the optional in.stream 2 Bluetooth
w/subwoofer system the following screens and functions will be available
on the control panel:
AUDIO
The main control panel is used with the in.stream 2 audio system. The
Audio screen in the Settings menu gives you the option to disconnect
your Bluetooth enabled device,
adjust the Fader, Balance or Sub
Woofer.
Use the or buttons to scroll
to desired option, press
(middle left) lit button to select the
function. Press the or
buttons to change parameters.
Press (top left) lit button to take
you back to the main Settings menu.
IN.STREAM 2 FUNCTIONS
Press the button in the home screen to access your audio system.
If you are using a device with Bluetooth technology, it must be connected
for functions to work.
Please note that the Play/Pause and Change Track functions apply to
devices using Bluetooth technology only, and will NOT work when AUX
is selected as the source.
Turning power on/off
Press the (top right) lit button to start the audio on or off process.
Selecting the source
Press the (top left) lit button
to select a source using
Bluetooth wireless technology or
AUX (aux is not available at time
of publication). Selection will be
indicated below In.stream 2.
Pairing Bluetooth
Audio Power must be on. Go to the Bluetooth settings on your device
and find in.stream 2 and press to connect. Enter pin 5555 and press pair
to sync your device. NOTE: Only one device at a time can be synced.
Play/Pause audio
Press the Play/Pause (middle right) lit button to start or pause the
audio. Press (middle left) lit button to mute or enable sound.
Adjusting the volume
Press the or buttons to increase or decrease the volume
illustrated by the slider bar.
Changing tracks
Use the Last Track and Next Track (lower left) lit button or
(lower right) lit button to change tracks.
TEMPERATURE CONTROL
The set temperature range is from 59°F to 104°F (15°C to 40°C). (The
water temperature of any
fitness system
may rise or lower slightly
depending on the current use and condition of your
fitness system
and
on outside temperatures.)
The set temperature of the
fitness system
water will automatically
be 85°F (29.5°C) the first time power is applied. This is the setting
programmed at the factory. After the
fitness system
has been set up
and used, the last temperature value set by the user will be stored
in memory. If power is disconnected from the
fitness system
, it will
automatically revert to the last set temperature when power is reapplied.
To display the set temperature of the
fitness system
:
Press the or buttons on the
control panel in the home screen.
To increase the set temperature of
the
fitness system
:
Press the button in the home
screen. The set point will appear in
blue. After 3 seconds without any
change to the set temperature
value, the current water temperature will reappear in white.
To decrease the set temperature of the
fitness system
:
Press the button in the home screen. The set point will appear in blue.
After 3 seconds without any change to the set temperature value, the
current water temperature will reappear in white.
Operating Instructions
