6
DRAINING YOUR ENDLESS POOL SWIM SPA
1) Disconnect electrical power to all pool equipment.
2) Begin to drain down pool water by placing a suitable sump
pump in the pool, or by setting up a siphon using a garden hose.
If using a siphon, two or more hoses may be used simultane-
ously in order to expedite the process.
3) When you are ready, refill the pool using a garden hose with a
“bobby filter” on the end to screen out debris and fine sediment.
If you do not have one of these filters, contact Endless Pools
Customer Service. If you have high calcium content and/or
high metal content in you area, you should also add some
“sequestering agent” to the pool water to help prevent scaling/
staining. Once again, if you do not have a bottle of this prod-
uct, contact us and we will send one out to you. You may also
be able to find both of these items at a local pool store.
4) The swim spa is full when the water completely covers the grill
at the front of the pool. Reestablish electrical power to the pool
equipment, and start balancing the pool water. Shock the pool
to 3.0 ppm free chlorine. Turn on your WQS in order to get
your new body of water filtered, circulated, and heated.
WINTERIZING YOUR ENDLESS
POOL SWIM SPA
An Endless Pool Swim Spa may be used year round, even in cold-
er climates. If you will not be using the swim spa during the win-
ter in an area where freezing is a problem, special consideration
must be taken to protect the pool and ancillary equipment if either
is located outside. If you have any questions regarding precautions
to take against freezing, please call our Customer Service
Department at (800) 910-2714.
SWIM SPA HEATER/CONTROLLER
The in.xe is a heater controller used by Endless Pools to control
the following water quality features:
• Water temperature can be set between 59ºF and 104ºF.
Default set point at 84ºF. The set point is changed with the
up and down keys.
• The Circulating Pump, CP, is always on. The heater can only
turn on when CP is on.
• Pressing the light key will turn lights on/off with an on time
of 120 minutes.
• Optional Pump #1 is for a single speed Jet pump. Pressing
the first key turns pump 1 on/off, with a run time of 30-min-
utes. The heating element is turned off when Pump #1 is
activated. To aid in filtration there are 4-purges per day.
• Optional UV always on except when Pump #1 is on and
remains off for 30-minutes after pump #1 is turned on.
• Holding first key for 5-seconds will turn off all devices for
30 minutes to allow for servicing. Pressing again will return
to normal operation.
WARNINGS:
Before installing or connecting the unit, please read the following.
• FOR UNITS FOR USE IN OTHER THAN SINGLE-FAMI-
LY DWELLINGS,A CLEARLY LABELED EMERGENCY
SWITCH SHALL BE PROVIDED AS PART OF THE
INSTALLATION. THE SWITCH SHALL BE READILY
ACCESSIBLE TO THE OCCUPANTS AND SHALL BE
INSTALLED AT LEAST 5 FEET (1.52 M) AWAY,ADJA-
CENT TO, AND WITHIN SIGHT OF THE UNIT.
• ANY DAMAGED CABLE MUST BE IMMEDIATELY
REPLACED.
• TURN POWER OFF BEFORE SERVICING OR MODIFY-
ING ANY CABLE CONNECTIONS IN THIS UNIT.
• TO PREVENT ELECTRIC SHOCK HAZARD AND/OR
WATER DAMAGE TO THIS CONTROL,ALL UNUSED
RECEPTACLES MUST HAVE A DUMMY PLUG.
• THIS CONTROLLER MUST NOT BE INSTALLED IN
PROXIMITY OF HIGHLY FLAMMABLE MATERIALS.
ELECTRICAL WIRING
For 240 VAC (4 wires)
Correct wiring of the electrical service box, GFCI, and pack ter-
minal block is essential.
Call an electrician if necessary.
Warning!
This product must always be connected to a circuit protected by
a ground fault interrupter.
Proper wiring of the electrical service box, GFCI and in.xe termi-
nal block is essential!
Check your electrical code for local regulations. Only copper wire
should be used, never aluminum.
To install the wiring for the in.xe heater controller, you'll need a
Phillips screwdriver and a flat screwdriver.
Loosen the 2 screws of the spa pack door and open it. Remove 5
1/2" of cable insulation. Strip away 1" of each wire insulation. Pull
the cable through the cutout of the box and secure it with a strain
relief (1" NTP strain relief; hole diameter: 1.335"). Make sure that
only the uncut sheathing is clamped at this opening. Push the color-
coded wires into the terminals as indicated on the sticker and use
the flat screwdriver to tighten the screws on the terminals.
After making sure wire connections are secure, push them back into
the box and close the door. Tighten the 2 screws of the sp pack door.
Connect the bonding conductor to the bonding lug on the front of
the in.xe spa pack. Use a minimum 8 AWG solid copper wire.
