Endress+ Hauser 7
h
~25 mm
(~1 in)
~75 mm
(~3 in)
h + 100 mm
(h + 4 in)
min. 200 mm
(min. 8 in)
de - Einstellhöhe markieren oder
Anschlag z.B. mit Schlauchschelle
en - Mark height or stop, e.g. hose clip
fr - Marquer la hauteur de réglage ou
butée, par ex. collier
es - Marcar altura o stop, ej. abrazadera
del tubo
it - Segnare l'altezza o fermare, p. e.
con una fascetta
nl - Instelhoogte markeren of stop, b. v.
slangenklem
Schaltpunkt
Switchpoint
Point de commutation
Punto de conmutación
Punto di commutazione
Schakelpunt

Endress+Hauser Liquiphant Specifications

General

Process Temperature	-50 to +150 °C (-58 to +302 °F)
Process Pressure	Up to 100 bar (1450 psi)
Output	Relay, NAMUR, PNP, 4…20mA
Approvals	ATEX, IECEx, FM, CSA
Housing Material	Aluminum
Connection	Threaded, flanged, or hygienic clamp
Protection Class	IP66
Electrical Connection	Cable gland
Power Supply	24 V DC, 230 V AC, or others depending on model
