Multiplexer Configuration Examples
Example 1: Multi/Single user system with 16 Cameras and Example 2: Multi/Single user system with 28 Cameras and
1 Multiplexer
2 Multiplexers
Dome ID Mux 01
01 –> Cam 1
02 –> Cam 2
03 –> Cam 3
04 –> Cam 4
05 –> Cam 5
06 –> Cam 6
07 –> Cam 7
08 –> Cam 8
09 –> Cam 9
10 –> Cam 10
11 –> Cam 11
12 –> Cam 12
13 –> Cam 13
14 –> Cam 14
15 –> Cam 15
16 –> Cam 16
Aux 1
Aux 2
Aux 3
Aux 4
Main Keyboard
Slave Keyboard 1
Slave Keyboard 2
Slave Keyboard 3
One Mux configuration
MUX A
Two Muxs configuration
MUX A MUX B
Dome ID Mux 01
01 –> Cam 1
02 –> Cam 2
03 –> Cam 3
04 –> Cam 4 ID Mux 02
05 –> Cam 5 17 –> Cam 1
06 –> Cam 6 18 –> Cam 2
07 –> Cam 7 19 –> Cam 3
08 –> Cam 8 20 –> Cam 4
09 –> Cam 9 21 –> Cam 5
10 –> Cam 10 22 –>
Cam 6
11 –> Cam 11 23 –>
Cam 7
12 –> Cam 12 24 –>
Cam 8
13 –> Cam 13 25 –>
Cam 9
14 –> Cam 14 26 –> Cam 10
15 –> Cam 15 27 –> Cam 11
16 –> Cam 16 28 –> Cam 12
Aux 1 Cam 13
Aux 2 Cam 14
Aux 3 Cam 15
Aux 4 Cam 16
Main Keyboard
Slave Keyboard 1
Slave Keyboard 2
Slave Keyboard 3
Aux 1
Aux 2
Aux 3
Aux 4
