9. Specifications
Art. No. Type Description
74219 EDC-KBD J-BOX
Junction box for EDC-KBD1, EDC-KBDM-3, KBD-2 series
Accessories
Model KBD-2
Art. No. 74149
Operation Mode
Single operation or 1 Master / 3 Slaves max.
Joystick
3-axis proportional joystick for manual control of variable speed
Multiplexer/camera control
up to 508 cameras
Site control (direct mode operation)
Keys select cameras and monitors, operate presets, patterns, auxiliaries, and sequences. Camera functions: pan,
tilt, zoom, focus, iris for fixed or variable speed control of the camera series Fastrax, Minitrax
Baud rate
2400 ~38400 Baud
Control functions
Joystick: Pan/tilt/zoom operation, Key switches: Zoom /focus/iris, Jog shuttle: smoother DVR control
Protocols
Fastrax IIE and Pelco P&D
Interface
2x RS-485 (dome cameras/DVRs, Recorder series DLR, DTR, DPR, and slave port. 1x RS-232C (optional junction
box EDC-KBD J-Box and DVR/PC port)
Remote control
Control of up to 254 Fastrax and/or Minitrax dome cameras. Up to 99 Digital Video recorders of the series DLR1.2,
DLR3/4, DPR, DIR and DTR
LCD display
16x2 characters
Supply voltage
12VDC (PSU 100~240VAC, 50/60Hz included)
Power consumption
3.0watts max.
Colour
Black
Temperature range
0 ~ +50°C
Dimensions
See drawing
Weight approx.
1.2kg
Parts supplied
Power supply unit 100 ~240VAC / 12VDC, 50/60Hz, Manual
Certificates
CE
Remarks For Master/Slave operation the article #902037 (EDC-KBD J-BOX) is requested. No Master/Slave operation
possible with keyboards EDC-KBD1 and EDC-KBDM-3
