Eneo KBD-2 - 2. Installation and Configuration; 2.1 Basic Configuration of Fastrax Dome System

5
Figure 2: Basic installation diagram
STP AWG #22
Power 24VAC
Sensor
BNC
Monitor
Alarm input
up to 8
Siren
Light
Alarm output
up to 4
Rear
Keyboard controller
Alarm output 1-2
Alarm input 1-4
Power 24VAC
Dome 1 +
Dome 1 –
Alarm output 3-4 Alarm input 5-8
BNC
RS-485
Half Duplex Mode: RX+ (TX+), RX- (TX-)
RS-422
Simplex Mode: (RX+), (RX-)
Duplex Mode: RX+ (TX+), RX- (TX-), (RX+), (RX-)
J-Box Dome
RS-485(+) DOME 1 + RX+ (TX+)
RS-485(-) DOME 1 - RX- (RX-)
2. Installation and Configuration
2.1 Basic Configuration of Fastrax Dome System
