Energic Plus 124TA1705 - Description; Technical Data

7/28
2. DESCRIPTION
2.1. Technical data
Always check the type plate for the correct information.
Frequency (Hz) 50 ÷ 60
Inrush current (A) < 2.35
Absorbed minimum power (W) < 10
Absorbed maximum power (kW) 7
Operating temperature (°C) From −20 to 50
Maximum relative humidity 90%
Switching frequency (kHz) 20 ± 5%
Height (A) (mm) 550
Width (B) (mm) 270
Depth (C) (mm) 120
Weight (kg) 9
Enclosure class IP20
C
A
B
