MENU ACCESS
When the charger is idle, press and hold <ESC>, the Main Menu is then displayed. The main
menu is automatically exited after 60 seconds of inactivity or can be exited voluntarily by pressing
the <ESC> button.
Main Menu
All menus are accessed from Main Menu; a detailed description of each menu is included in the
next sections of this manual. The menus that require a password are not displayed until the
correct password has been entered.
The menus provide access to the following functions:
View last 200 charging cycles (Memo menu).
View of faults, alarms, etc. (Status menu).
USB functions (USB menu).
Setting of date, language and others (Parameters menu).
Management of password (Password menu)
MEMORIZATIONS
Memorizations Display Screen
The charger can display the details of the last 200 charge cycles.
The display below shows one charge stored in memory. MEMO 1 is the latest charge
memorized. After memorizing the two-hundredth charge, the oldest record is deleted and
replaced by the next oldest.
Displaying a Charge Cycle
Proceed as follows:
1. Select a record (MEMO x) using the ▲/▼ buttons.
2. Display the first History screen by pressing Enter.
3. Display the second History screen by pressing▼.
4. Return to the Main Menu by pressing Esc.
The charge history is displayed; use the ▲/▼ to scroll through the parameters.
