TECHNICAL INFORMATION
Technical Information (cont.)
Output Power (kW) Number Modules Module Power (kW)
1.0 1 1.0
2.0 2 1.0
3.0 3 1.0
3.5 1 3.5
7. 0 2 3.5
10.5 3 3.5
14.0 4 3.5
1 7. 5 5 3.5
21.0 6 3.5
24.5 7 3.5
28.0 8 3.5
Output Power Letter Codes
Phases Module Positions
Standard Cable
Gauge
Comments
1ph Max 1 6 mm
2
Stand-alone cabinet
1ph Max 3 25 mm
2
Three-slot, 3 kW cabinet
3ph Max 2 35 mm
2
Two-slot, 7 kW cabinet
3ph Max 4 70 mm
2
Four-slot, 3.5 to 14 kW cabinet
3ph Max 6 95 mm
2
Six-slot, max 21 kW cabinet
3ph Max 8
70 mm
2
or
1 x 95 mm
2
Eight-slot, max 28 kW cabinet.
Dual cable for 24/36/48Vdc, single cable for
72/80Vdc
Cabinet Size (number of modules available) and DC Cable Size
Prole Code Charger Prole Description
P19 FAST
Fast prole for ooded battery equipped with airmix. Charger rate up to
0.4 C5. Must set battery capacity, temperature & equalize values and t
properly programmed Wi-iQ
®
battery monitoring device (FAST EU). If not
installed or no Comm, charger will use STDWL prole. Weekly equalization
of 8h is needed. Recommended parameters to set on the charger.
P22 HDUTY
Heavy duty wet cell pulse prole. The charge prole diagnoses the
battery status throughout the recharge phase and adjusts its parameters
to optimize the charge of ooded battery technology. Max 0.25 C5. Auto
battery capacity matching with continuous current loops.
P21 STDWL
Standard (Water Less
®
) wet cell prole. IUI prole Max 0.13 to 0.20 C5.
Auto battery capacity matching with Ph1 loops. Can manually set battery
capacity if required. Weekly equalization is needed.
P02 GEL
IUI prole. Max 0.17 to 0.22 C5. Auto battery capacity with Ph1 loops. Can
manually set battery capacity if required. Weekly equalization is needed.
Charge Prole Codes
