TECHNICAL INFORMATION
Technical Information (cont.)
P06 AGM
IUI prole. Max 0.20 C5. Auto battery capacity with Ph1 loops. Finish
time limitation. Can manually set battery capacity if required. Weekly
equalization is needed.
P07 OPP (*)
Opportunity charge PzQ cells. IU (main) & IUI pulse (daily) prole @0.25
C5. Finish current 5%. Must set daily full charge. If programmed
Wi-iQ
®
battery monitoring device tted, gives capacity, temp and voltage;
however, for safety if no communication, should manually set battery
capacity, temp and voltage. Weekly equalization is needed.
P04 AIRMIX
Pneumatic/Airmix prole. Must have air kit tted to use this prole. IUI
prole Max 0.13 to 0.25 C5. Auto battery capacity with Ph1 loops. Can
manually set battery capacity if required. Weekly equalization is needed.
P09 WL20
Water Less
®
20 battery, IUI prole (old WF200). Requires airmix and Wi-iQ
®
battery monitoring device comm. Weekly equalization is needed.
P25 LOWCHG
Low rate charge prole. IUI prole 0.09 to 0.13 C5. Manually set battery
capacity if required. Weekly equalization is needed.
P31 NXBLOC (*)
For NexSys
®
TPPL Bloc battery under normal charge. Charge rate 0.18 to
0.70 C5. Must set Battery Capacity, Temperature & Equalize values, or t
properly programmed Wi-iQ
®
battery monitoring device (NexSys
®
BLOC
battery). If not installed or no comm, charger will use manual setup Ah and
temp. Weekly equalization is needed.
P29 NXSTND (*)
For NexSys
®
TPPL 2V battery under normal charge. Charge rate 0.18 to 0.25
C5. Must set battery capacity, temperature & equalize values or t properly
programmed Wi-iQ
®
battery monitoring device (NexSys
®
2V battery). If not
installed or no comm, charger will use manual setup Ah and temp. Weekly
equalization is needed.
P30 NXFAST (*)
For NexSys
®
TPPL 2V battery under fast, higher rate. Charge rate 0.251 -
0.40 C5. Properly FAST programmed Wi-iQ
®
battery monitoring device
(NexSys
®
2V battery). If not installed or no comm, charger will use manual
setup Ah and temp. Weekly equalization is needed.
P32 NXP2V (*)
For NexSys
®
TPPL 2V battery under fast, higher rate. Charge rate 0.18 - 0.40
C5. Properly programmed Wi-iQ
®
battery monitoring device (NexSys
®
TPPL
2V battery). If not installed or no comm, charger will use manual setup Ah
and temp. Weekly equalization is needed.
P33 NXPBLC (*)
For NexSys
®
TPPL Bloc battery under normal charge. Charge rate 0.18 to
0.70 C5. Properly programmed Wi-iQ
®
battery monitoring device (NexSys
®
TPPL Bloc battery). If not installed or no comm, charger will use manual
setup Ah and temp. Weekly equalization is needed.
ATP2V
For NexSys
®
ATP 2V battery under fast, higher rate. Charge rate 0.2 to
0.5 C5. Properly FAST programmed Wi-iQ
®
battery monitoring device
(NexSys
®
ATP 2V). If not installed or no communication, charger will use
setup Ah and temperature. Float ON have to be set. I
Float
= Round (roundup
[Battery Voltage x Battery Capacity]/1000 x 0,1).
NXSION (*)
For Enersys
®
lithium battery only. The charger is communicating with
the Enersys
®
lithium BMS through the CANBUS, the BMS is driving
the charger and then the setting of the charger is not compulsory.
Nevertheless, there are recommended parameters to set on the charger.
Prole Code Charger Prole Description
