38 Solution 1.8 Insert Installation and Operation Manual
CLEARANCES
F
13" (330 mm)
G
10" (254 mm)
H
22" (559 mm)
I
29" (737 mm)
O
1 1/2" (38 mm)
MINIMUM MASONRY
OPENING
J
21 3/8" (543 mm)
K
28 7/8" (733 mm)*
L
12 3/4" (324 mm)
FLOOR PROTECTION
CANADA USA
B
18’’ (457 mm) – Note1 16’’ (406 mm) – Note 1
M
8’’ (203 mm) N/A (Canada only)
N
N/A (USA only) 8’’ (203 mm)
Minimum floor to ceiling clearance: 84’’ (213 cm)
* Where a fresh air intake is needed, we suggest you add a minimum of 4’’ to the width of the
minimum masonry opening.
Note 1: From door opening. The depth of a non-combustible mantel in front of the insert is
included in the calculation of the floor protector’s dimensions.
IMPORTANT: The masonry hearth should be at least 4 inches (102 mm) higher than the
combustible floor in front of it. If the hearth elevation is lower than 4 inches, the non-
combustible floor protector in front of the insert should have an R value equal or greater than
1.00.
