Appendix 5: Installation of Secondary Air Tubes and Baffle

LETTER DESCRIPTION QUANTITY

BAFFLE HOLDER 1

SECONDARY AIR TUBE 3

COTTER PIN 3

C-CAST BAFFLE 1

INSULATION BLANKET 1

INSULATION BLANKET WEIGHT 1
