Solution 1.8 Insert Installation and Operation Manual 49
Partially thread the screws (F) on the
trim's corner bracket (G) then
superimpose the corner brackets (G) and
(H) as shown in the image on the left.
Insert the superimposed brackets (G) and
(H) with the screws (F) in the groove of
each decorative trim (I), (J) and (K). Align
the corners of the angled side of each
trim, and then tighten the screws (F) to
secure the trims.
Enclose the decorative inserts (L) from
behind the lower parts of the faceplate.
The decorative inserts are included in the
owner’s manual.
