58 Solution 1.8 Insert Installation and Operation Manual
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for
your stove, please provide the model number and the serial number. We reserve the right to
change parts due to technology upgrade or availability. Contact an authorized dealer to obtain any
of these parts. Never use substitute materials. Use of non-approved parts can result in poor
performance and safety hazards.
# Item Description Qty
1 AC01252 GOLD CAST IRON DOOR OVERLAY 1
1 AC01254 NICKEL CAST IRON DOOR OVERLAY 1
1 AC01250 BLACK CAST IRON DOOR OVERLAY 1
2 30123 SCREW #8 - 32 X 5/8'' PAN QUADREX ZINC 6
3 AC07868 1/2 " BLACK COIL HANDLE 1
4 SE53580 BLACK CAST IRON DOOR WITH GASKET 1
5 AC09170 REMPLACEMENT HANDLE AND LATCH KIT 1
6 30205 ZINC WASHER ID 13/32" X OD 13/16" 2
7 30533 LATCH KEY PATH PIN 1
8 30033 STEEL DOOR LATCH 1
9 30224 LOCKNUT 3/8"-16 HEX 1
10 AC06500 SILICONE AND 5/8" X 8' BLACK GASKET KIT 1
11 SE53582 REPLACEMENT GLASS WITH GASKET 9 13/16" X 17 3/32" 1
12 AC06400 BLACK SELF-ADHESIVE GLASS GASKET (6') 1
13 PL53583 GLASS RETAINER FRAME 2
14 SE53585 GLASS RETAINER KIT WITH SCREWS (12 PER KIT) 1
15 30124 SCREW #8 - 32 X 5/16'' TRUSS QUADREX ZINC 6
16 PL53550G BRASS "U" SHAPED SIDE DECORATIVE ACCENT 4
16 PL53554 NICKEL "U" SHAPED SIDE DECORATIVE ACCENT 4
16 PL53554G BRASS "U" SHAPED SIDE DECORATIVE ACCENT 4
16 PL53550 NICKEL "U" SHAPED SIDE DECORATIVE ACCENT 4
17 PL53871 LEFT DECORATIVE PANEL 1
18 PL53870 RIGHT DECORATIVE PANEL 1
19 PL53869 FACEPLATE EXTENSION 1
20 PL34052 LINER FIXATION BRACKET 3
21 30337 SQUARE HEAD SET SCREW 1/2-13 X 1-3/4" 2
22 AC01298 FRESH AIR INTAKE KIT - OVAL 5" DIAMETER 1
23 PL53529 AIR CONTROL PLATE 1
24 30187 ZINC WASHER ID 17/64" x OD 1/2" 1
25 30206 ZINC WASHER ID=5/16" x OD=3/4" 1
26 30064 3/16" X 1" CLEVIS PIN 1
27 30059 5/32" ID PUSHNUT 2
28 30060 THREAD-CUTTING SCREW 1/4-20 x 1/2" F HEX STEEL SLOT WASHER C102 ZINC 1
29 SE53608 AIR CONTROL ROD ASSEMBLY 1
30 30102 1/4'' CAST IRON AIR CONTROL HANDLE 1
