Engcon EC209 - 9.1. Tiltrotator Data by Model

9 Technical data
Description
EC204
EC206
EC209
EC214
EC219
EC226
EC233
Rec open/close
pressure SQ S30-
S3, HS03/08
MPa
21 / 3-6
21 / 3-6
21 / 3-6
21 / 3-6
21 / 3-6
21 / 3-6
21 / 3-6
Rec open/close
pressure SQ
ECpup
MPa
NA
21 /
10-21
21 /
10-21
21 /
10-21
21 /
10-21
21 /
10-21
21 /
10-21
Rec open/close
pressure SQ Q-
Safe
MPa
NA
21
21
21
21
21
21
Weight
kg*
116
170
287
385
447
632
812
Width (A)
mm*
267
286
277
320
396
426
501
Width (B)
mm*
161
220
250
285
315
340
385
Width (C)
mm*
169
219
273
303
310
340
385
Overall length (D)
mm*
463
500
561
665
737
760
878
Construction height
(E)
mm*
from
310
from
380
from
425
from
457
from
480
from
500
from
673
Swivel channel
extra function,
number of ports
2
4
4
4
4
4
4
Swivel channel
locking function,
number of ports
2
2
2
2
2
2
2
Rotation
∞
∞
∞
∞
∞
∞
∞
Tilt angle
°
2×45
2×45
2×45
2×45
2×45
2×45
2×45
Tilt duration from
end position to end
position
s / l/min
3/7
3/15
3/34
3/40
3/65
5/43
5/63
Rotation duration
for one rotation
under hydraulic
flow
s / l/min
7/21
6.5/30
7/40
7/50
6.5/70
7/70
10/70
Standard
dimension, extra
port***
1/4"
3/8"
3/8" +
1/4"
1/2" +
1/4"
1/2"+
1/4"
(3/8")*
3/4"
3/4"
Oil flow max
standard (extra)****
l/min
20
35
50
100
100
100
100
Table 21.
*Standard attachment
** [l/min] with High Flow
