11 Interfaces and Options
11.1 Optical (infrared) interface
For the communication with the optical interface an optocoupler and the ‘Device Monitor’ is necessary. The
optocoupler and the ‘Device
Monitor’ software are available as accessory equipment.
Baud rate: 2400 baud
11.2 Radio interface wireless M-Bus (optional)
The radio interface is for the transmission of meter data (absolute values).
General information about the radio interface
When installing the radio components, avoid metallic material directly in front of the housing.
The transmission quality (range, telegram processing) of radio components can be negatively influenced by
instruments or equipment with electromagnetic emissions, such as telephones (particularly LTE mobile radio
standard), wi-fi routers, baby monitors, remote control units, electric motors, etc.
In addition, the construction of the building has a strong influence on the transmission range and coverage.
The factory-setting of the internal clock inside the heat cost allocator is standard (winter) Central European
Time (GMT +1). There is no automatic changeover to daylight savings (summer) time.
The radio function is deactivated upon delivery (see 11.2.6 “Activation of the radio interface”)
11.2.1 Technical data radio
short telegram AMR (in conformity to
serial number, date/time, current consumption, due date, due date
value, hint flag, time of hint flag
- long telegram for walk-by read-out:
serial number, date/time, current consumption, due date, due date
value,
15 monthly values, 15 semimonthly values, hint flag, time of hint flag
AES: Advanced Encryption Standard; key length: 128 bits
11.2.2 Radio configuration
S1 / T1 / C1; unidirectional
12:00 pm; any time period in the day
uninterrupted, incl. a possible 5
annually variable (except 29.02.)
- customer specific key
- random key per instrument
- long telegram for walk-by read-out
