Logged Diagnostics: Use the UP/DOWN soft keys and stop the cursor (. .) next to the action
item Logged Diagnostics. Press the select ( ) soft key. The screen displays the controller
requests DM2 (stored trouble codes, not active), warning or faults from the ECU. Each
diagnostic is shown with the appropriate information:
• Suspect Parameter Number (SPN)
• Failure Mode Indicator (FMI)
• Text Description (if available)
• ID/Name of the device that transmitted the DM1 message
NOTE: Select the Freeze Frame Button to requests the freeze frame data
from the ECU when faults are present.
