IQ8MC, IQ8AC, IQ8HC, and IQ8X Microinverters Installation and Operation Manual
16 © 2023 Enphase Energy Inc. All rights reserved. November 2023
USM-00008-2.0
Step 1: Position the IQ Cable
A. Plan each cable segment to allow drop connectors on the IQ Cable to align with each PV module. Allow extra
length for slack, cable turns, and any obstructions.
B. Mark the approximate centers of each PV module on the PV racking.
C. Lay out the cabling along the installed racking for the AC branch circuit.
D. Cut each segment of cable to meet your planned needs.
WARNING: When transitioning between rows, secure the cable to the rail to prevent cable or connector
damage. Do not count on the connector to withstand tension.
Step 2: Position the junction box
A. Verify that the AC voltage at the site is within range.
NOTE: All installations require that you use the IQ Gateway to commission the microinverters to propagate
correct grid profile settings. This will also ensure that the microinverter's firmware is upgraded whenever a
newer version is available.
* Only IQ8HC supports 220 V Grid in Mexico.
B. Install a junction box at a suitable location on the racking.
C. Provide an AC connection from the junction box back to the electricity network using equipment and
practices as required by local jurisdictions.
Step 3: Mount the microinverters
A. The microinverters should be mounted beneath the modules either horizontal bracket side up or vertical
orientation to the module and must be protected from direct exposure to rain, UV, and other harmful weather
events. Please refer to the image below for clearance requirements during vertical mounting.
• Always place the microinverter under the PV module, protected from direct exposure to rain, sun, and
other harmful weather events. Allow a minimum of 1.9 cm (3/4 in) between the roof and the microinverter.
Also, allow 1.3 cm (1/2 in) between the back of the PV module and the top of the microinverter.
• For vertical mount, maintain >30 cm (12 in) clearance from the edges of the PV module to protect the
microinverter from direct exposure to rain, UV, and other harmful weather events.
WARNING: Install the microinverter under the PV module to avoid direct exposure to rain, UV, and other
harmful weather events. Do not mount the microinverter upside down.
B. Torque the microinverter fasteners as follows. Do not over-torque.
• 6 mm (¼ in) mounting hardware: 5 N m (45 in-lbs. to 50 in-lbs.)
• 8 mm (5/16 in) mounting hardware: 9 N m (80 in-lbs. to 85 in-lbs.)
• When using UL 2703 mounting hardware, use the manufacturer's recommended torque value.
Service type and voltage: L1-L2
240 VAC split-phase 211 to 264 VAC
208 VAC single-phase 183 to 229 VAC
220 VAC single-phase* 198 to 264 VAC
