EVR AUTOMATIC RECLOSER http://www.entecene.co.kr
21
ENHANCED TECHNOLOGY
4. PACKING, HANDLING AND STORAGE
4.1. PACKING AND DESPATCH
Each recloser is normally packed in one non returnable case or wooden crate for exporting and in
home is mounted on a transit pallet.
The recloser is despatched in the closed position for convenience and filled with SF6 gas to the
commissioning pressure before despatch.
The recloser and control cubicle are disconnected with umbilical cable connection for
transportation and standard pole mounting bracket of the main Tank are despatched as loose
equipment in the wooden crate of the recloser.
Table 4-1. Approximate weights
Unit 15kV 27kV 38kV
Circuit breaker with gas kgf 160 170 210
Control Cubicle with battery kgf 80 80 85
Control cable kgf 3.5 3.5 3.5
Mounting bracket kgf 38 38 42
Gross weight in packing kgf 320 330 380
4.2. UNPACKING AND HANDLING
The wooden crate should be transported by hand pallet or forklift truck.
The lifting procedures should be kept for safety and we recommend slinging as shown in Figure 4-
1 and ensure the following procedures.
1) The slings should be approved and in good condition.
2) The lifting hook should be placed above the level of the bushings.
3) When moving the unpacked units, please maintain the lifting level to 30ć above ground level,
if possible, to avoid the damage due to unexpected failure.
4) 4Please be sure to balance the main tank weight so that the rope does not touch both sides of
bushings throughout the transportation.
5) When moving and lifting, special care should be taken not to damage the bushings and bushing
terminals.
