6) Lifting method is shown in Figure 4-1.
Min. 100mm
Figure 4-1. Lifting configuration of the reclsoer
CAUTION: Do not touch severely Bushing or Bushing Terminal during transporting the main
tank of recloser. It causes a leakage of SF6 gas or damage on the bushing which leads to a severe
malfunctions of the recloser.
4.3. RECEIVING
A packing list will be attached to the packing case or recloser if not packed.
On receipt, the recloser should be checked for the contents of deficiency or damage during
transportation. Please inform within 3 days to either the carriers, supplying agent or customer
services department of the ENTEC Electric & Electronic Company., Ltd., if any damage was found.
4.4. STORAGE
As the recloser is designed for outdoor use, it can be stored both outdoor and indoor but the
recloser should not be stored in a wet place and should not stacked up doubled.
