Hardware Installation
2-2
• Using the mounting bracket, mark the position of the four screw holes on the wall
or ceiling. For concrete or brick walls, you will need to drill holes and insert wall
plugs for the screws.
• Position the mounting bracket over the wall or ceiling screw holes, then insert the
included screws and tighten them down to secure the bracket firmly to the wall or
ceiling.
• Attach the access point to the mounting bracket. Line up the two mounting points
on the access point with the two mounting slots on the bracket (see the following
figure). Place the mounting points of the access point into the mounting slots of the
bracket, slide it into position so that the bracket fastening screw on the access point
lines up with the tab on the bracket. Then screw down the fastening screw to
secure the access point to the bracket.
Mounting
Points
Mounting
Slots
Fastening
Screw
Align this tab with
the Fastening
Screw
To Next Page
