9
IP1851EN - 2013-05-06
7. Settings
7.1 Trimmers
7.2 Sliding gates dip-switches
Trimmer Description
VA - VC
MAX
MIN
VA - Opening speed adjustment. Adjusts the opening speed.
VC - Closing speed adjustment. Adjusts the closing speed.
TC
MIN=0 s MAX=disabled
Setting automatic closing time.
From 0 to 120 s.
With DIP3A=OFF, once a safety switch has been activated, the counter starts as soon as the safety switch is re-
leased (for example, after passing through the photocells), and lasts for a period of time set with TC (50%).
WARNING: with QIK automations, automatic closing is immediate.
With DIP3A=ON, the counter starts when automation is opened and lasts for the entire duration set with TC (100%).
N.B.: after the activation of the stop command, once contact 1-9 has closed again, automatic closing is only ena-
bled after a total, partial or step-by-step opening command.
TC
MIN=0 s MAX=120 s
With DIP3B=OFF, permanent closing of contact 1-20 enables automatic closing.
CROSS
MAX
MIN
Power setting.
The control panel is equipped with a safety device that stops motion if an obstacle is encountered during the open-
ing operation and reverses motion during the closing operation.
QIK
Adjustment of power and stop distance.
It adjusts the power of the automation.
With DIP7B=OFF, it adjusts the closing bar stop distance.
DIP A Description OFF
ON
DIP1A Command functions 1-5.
N.B.: it also sets operating on the AUX
plug-in card.
Step-by-step Opening.
DIP2A Selecting opening direction.
The opening direction is in-
tended by viewing the automa-
tion from the side being examined.
Opening to the right. Opening to the left.
DIP3A Automatic closing time restore 50% 100%
DIP4A Automation status at power on.
Indicates how the control panel considers
automation when powered up.
Open.
N.B.: with limit switches installed, we rec-
ommend setting DIP4A=OFF.
Closed.
N.B.: if the automatic closing function is
not used, we recommend setting DIP4=ON.
DIP5A Preashing for 3 seconds. Disabled during opening.
Enabled only with automatic closing with
TC >3 s.
Enabled for both opening and closing.
DIP6A Safety test terminal 41. Disabled. Enabled.
DIP B Description OFF
ON
DIP1B Reversal safety contact operation. With automation stopped and contact 1-8
open, opening operations are permitted.
With automation stopped and 1-8 open, all
operations are disabled.
DIP2B Command functions 1-6. Closing. Stop.
DIP3B Command functions 1-20. Automatic closing on. Partial opening command.
DIP4B Selection of maximum working forces lim-
it and adjustment of stop distance.
Normal closing force and reduced stop
distance that changes according to speed.
Reduced closing force and longer stop
distance irrespective of speed.
DIP5B Encoder selection. Automation without encoder.
N.B.: stop limit switches must be installed.
Automation with encoder.
DIP6B Current profile.
(Automations with encoder only).
Disabled. Enabled.
DIP7B Approach speed adjustment. Normal. Reduced.
DIP8B Electronic antifreeze system.
Maintains motor efficiency even at low
ambient temperatures.
Enabled. Disabled.
