10
IP1851EN - 2013-05-06
7.4 Jumpers
Jumper Description OFF ON
JR1 Built-in radio receiver Disabled Enabled
7.3 Barrier dip-switches
DIP A Description OFF
ON
DIP1A Command functions 1-5.
N.B.: it also sets operating on the AUX
plug-in card.
Step-by-step Opening.
DIP2A Selecting opening direction.
The opening direction is intended by view-
ing the automation from the side being
examined.
Opening to the right. Opening to the left.
DIP3A Automatic closing time restore 0% 100%
DIP4A Automation status at power on.
Indicates how the control panel considers
automation when powered up.
Open.
N.B.: with limit switches installed, we rec-
ommend setting DIP4A=OFF.
Closed.
N.B.: if the automatic closing function is
not used, we recommend setting DIP4=ON.
DIP5A Operating of output 0-14 and C-NO con-
tact.
Flashing light and courtesy light. Flashing light, lighting kit and electric
block.
Preashing for 3 seconds. Enabled only with automatic closing with TC >3 s.
DIP6A Safety test terminal 41. Disabled. Enabled.
DIP B Description OFF
ON
DIP1B Reversal safety contact operation. With automation stopped and contact 1-8
open, opening operations are permitted.
With automation stopped and 1-8 open, all
operations are disabled.
DIP2B Command functions 1-6. Closing. Stop.
DIP3B Preashing for 3 seconds.
After intervention of safety switch 1-8 and
with immediate closing DIP3A=OFF
Disabled Enabled
DIP4B Selection of maximum working forces lim-
it and adjustment of stop distance.
Normal closing force and reduced stop
distance that changes according to speed.
Reduced closing force and longer stop
distance irrespective of speed.
DIP5B Stopping type selection. Immediate. Normal.
DIP7B Stop distance adjustment during closing. It allows the adjustment of the stop dis-
tance by means of trimmer R1.
Stopping fixed at 30°.
DIP8B Electronic antifreeze system.
Maintains motor efficiency even at low
ambient temperatures.
Enabled. Disabled.
