12
ROTISSERIE INSTALLED ONTO CART ASSEMBLY (OPTIONAL):
Components Required:
● Rolling cart with engine ● Rotisserie Motor ● Side mount bracket
● (3) Stainless steel thread rolling screws ● Rotisserie rod ● (2) Spit forks
● Spit bushing ● Counter weight assembly
Figure 20
1. Install the motor mounting bracket onto the left side of the engine with the three (3) screws provided.
2. Slide the rotisserie motor into the mounting bracket.
3. Place the forks, counterweight, and spit bushing onto the rotisserie rod (see Figure 20). If cooking a large item
on the rotisserie, the forks are not mandatory.
4. Slide the pointed end of the rotisserie rod into the rotisserie motor and rest the groove in the bushing on the
notched right side of the windshield.
NOTE: DO NOT USE ROTISSERIE MOTOR IN THE RAIN AND REMOVE MOTOR WHEN NOT IN USE.
DO NOT USE THE WARMING RACK IF THE ROTISSERIE IS BEING USED.
GRILL REMOVAL:
Figure 21
