15
Installation
QUALIFIED INSTALLERS ONLY
Step 6: Fasten the top standoff to the Side Vent body using your T20 screwdriver and T20 screws
provided.
Step 7: Place your block off plates on the sides of the side vent body not in use.
NOTE: The Cool Surface Systme will not fucntion properly if the block of plates are not installed.
side vent:
Figure 21. CSS Side Vent Assembly
Figure 22. CSS Side Vent block off plate adjustment
